36W led spot light

36W led spot light

Ultra-bright 36W RGB waterproof Led spotlight with AC85-245V AC, Cree or Epistar led chip for outdoor.Features:1.Adopt high Led as light source. Energy-saving up to 80%, environment protection and long lifetime
  • Light Type :

    Led Flood Lights
  • Product Code :

    CS-TG064
  • Chip Brand :

    CREE/ EPISTAR
  • Dimension :

    W325x200xH160mm
  • Material :

    Aluminum Body+tempered Glass Cover
  • Rated Power :

    36W
  • Light Color :

    Single, RGB
  • Rated voltage :

    AC180~245V
  • Protection level :

    IP65
  • Warranty time :

    2-3years
  • Product Details
  • Packing&Size


Specification

Chip Brand: USA CREE/ EPISTAR
Rated power:18W/24W/36W/60W/108W
Material: aluminum alloy + tempered glass
Light source: 1W/1.5W high power led
LightsCircuit board: aluminum plate
Number of light sources: 18/24/36/60/72 PCS
Rated voltage:AC180~245V
Beam angle:5°,8°,12°,24°,36°
Light color: Single or RGB
Working temperature:-30°C-55°C
Protection level:IP65
Life span:30000hrs
Warranty time:2-3Years
Lamp body size:W325x200xH160mm
Lamp body color: polyester powder fly ash
Butt plug: three-core rubber line
Production process: resin plastic potting waterproof
Single brightness: 80-90Lm / W
Electrical class: Class I
Luminous mode: always bright, colorful color
Rotation angle:160°
Control method:N/A


Order Product Code:

No. ITEM NO LED QTY Light Color Lumens Voltage Wattage Control Dimension Remarks
1 CS-TG063-18W 18PCS-1W Single ≤1530LM AC85~245V 18W N/A W225x138x160mm
2 CS-TG063-24W 24PCS-1W Single ≤2040LM AC85~245V 24W N/A W225x138x160mm
3 CS-TG064-36W 36PCS-1W Single ≤3060LM AC85~245V 36W N/A W225x200x160mm
4 CS-TG065-60W 60PCS-1W Single ≤5100LM AC85~245V 60W N/A W440x248x150mm
5 CS-TG066-108W 72PCS-1.5W Single ≤7920LM AC85~245V 108W N/A W560x330x230mm







led outside flood lights
