SMD3030 good quality street lights

SMD3030 good quality street lights

SMD3030 good quality street lights
  • "Model :

    CS-ST007
  • Power :

    50W/100W/150W
  • Material :

    die-cast aluminum
  • IP Rating :

    IP65
  • Led chip :

    SMD3030
  • Driver :

    Meanwell
  • Warranty :

    3 years "
  • :

  • Product Details
  • Packing&Size

This led street light design has two type. One is for the SMD led chip, Another one is for the COB led chip.

For COB led chip design. You can check this it by bellow link:https://www.cslamp.com/products-show/led-street-light--style-04.html



Item No

CS-ST007-50W

CS-ST007-100W

CS-ST007-150W

Dimension L*W*H(mm)

500*212*63MM

725*280*80MM

855*330*82MM

Installation Height

5-6M

7-8M

8-10M

Luminous flux

5500LM

11000LM

16500LM

LED Type

SMD3030

SMD3030

SMD3030

LEDs qty

90pcs

180pcs

360pcs

Material

Aluminum

Aluminum

Aluminum

Install pole diameter

50mm

60mm

60mm

Beam angle

70*140°

70*140°

70*140°

Power factor

>0.98

>0.98

>0.98

CRI

>80

>80

>80

Lifetime

50000hrs

50000hrs

50000hrs

Waterproof

IP65

IP65

IP65

Color

3000-6000K

3000-6000K

3000-6000K

Warranty

3years

3years

3years

Packing QTY

1PCS

1PCS

1PCS

Packing Size

510*220*90mm

745*290*110mm

880*335*115mm
